APC by Schneider Electric Smart-UPS 2200VA Rack-mountable UPS - SMT2200R2X658

    Product form
    • Schneider Electric SA

    APC by Schneider Electric Smart-UPS 2200VA Rack-mountable UPS - SMT2200R2X658

      General Information Manufacturer: Schneider Electric SA Manufacturer Part Number: SMT2200R2X658 Manufacturer Website Address: http://www.schneider-electric.com Brand Name: APC by Schneider Electric... Read more

      Direct Ship From Manufacturer, Lead Time May Apply.

      $1,810.78

        • Need Presales Support? Contact Sales at 877-712-2230 or sales@itosolutions.net.
        • Warranty by Manufacturer
          Have a question on this product? Fill out the form below.
        Send us a message!

        SKU: NB1603
        Barcode: 0731304293330

        Size chart

        General Information

      • Manufacturer: Schneider Electric SA
      • Manufacturer Part Number: SMT2200R2X658
      • Manufacturer Website Address: http://www.schneider-electric.com
      • Brand Name: APC by Schneider Electric
      • Product Line: Smart-UPS
      • Product Name: Smart-UPS 2200VA Rack-mountable UPS
      • Marketing Information:

        Marketing Information from the Manufacturer


      • Product Type: Line-interactive UPS

        • Technical Information

      • AVR: Yes
      • Plug/Connector Type: NEMA 5-20P
      • Receptacle Type:
        • NEMA 5-15R
        • NEMA 5-20R

      • Receptacle Detail:
        • 6 x NEMA 5-15R
        • 2 x NEMA 5-20R

      • Number of Battery & Surge Outlets: 8
      • Application/Usage:
        • Server
        • Electronic Device
        • Storage Device
        • Network
        • Business

        • Power Description

      • Load Capacity (VA): 2200 VA
      • Load Capacity (Watt): 1980 W
      • Input Voltage: 120 V AC
      • Input Voltage Range: 82 V AC - 144 V AC
      • Output Voltage: 120 V AC
      • Input Frequency: 60 Hz
      • Output Frequency: 63 Hz
      • Waveform Type: Pure Sine Wave
      • Surge Energy Rating: 530 J

        • Management

      • Alarm:
        • On Battery
        • Low Battery
        • Fault

        • Controls/Indicators

      • Status Indicators:

        LED Indicators:

        • On Line
        • On Battery
        • Replace Battery
        • Overload

        Intuitive LCD Display:

        • Load capacity
        • Battery charge level
        • Estimated runtime

        • Interfaces/Ports

      • USB (HID Compliant) Port: Yes

        • Battery Information

      • Number of Batteries: 1
      • Battery Characteristics: Maintenance-free, Sealed, Spill-proof
      • Battery Chemistry: Lead Acid
      • Backup/Run Time (Full Load): 5.10 Minute
      • Backup/Run Time (Half Load): 15.20 Minute
      • Typical Battery Recharge Time: 3 Hour
      • Replaceable Battery: Yes

        • Physical Characteristics

      • Height: 3.40"
      • Width: 18.90"
      • Depth: 26.90"
      • Rack Height: 2U
      • Form Factor: Rack-mountable
      • Weight (Approximate): 93.08 lb

        • Miscellaneous

      • Environmentally Friendly: Yes
      • Environmental Compliance:
        • Restriction of Hazardous Substances (RoHS)
        • Registration, Evaluation, Authorization and Restriction of Chemicals (REACH)

        •
