APC by Schneider Electric Symmetra LX 16000VA Tower UPS - SYAF16KXR9T

    Product form
    • Schneider Electric SA

    APC by Schneider Electric Symmetra LX 16000VA Tower UPS - SYAF16KXR9T

      General Information Manufacturer: Schneider Electric SA Manufacturer Part Number: SYAF16KXR9T Manufacturer Website Address: http://www.schneider-electric.com Brand Name: APC by Schneider Electric... Read more

      Direct Ship From Manufacturer, Lead Time May Apply.

      $11,055.68

      Business-to-Business Sales Only
      We sell exclusively to businesses, government agencies, educational institutions, organizations, and U.S. military bases within the United States. A valid business email address is required.

        • Need Presales Support? Contact Sales at 877-712-2230 or sales@itosolutions.net.
        • Warranty by Manufacturer
          Have a question on this product? Fill out the form below.
        Send us a message!

        SKU: TT7625

        Size chart

        General Information

      • Manufacturer: Schneider Electric SA
      • Manufacturer Part Number: SYAF16KXR9T
      • Manufacturer Website Address: http://www.schneider-electric.com
      • Brand Name: APC by Schneider Electric
      • Product Line: Symmetra LX
      • Product Name: Symmetra LX 16000VA Tower UPS
      • Packaged Quantity: 1 / Pack
      • Product Type: Double Conversion Online UPS

        • Technical Information

      • Plug/Connector Type: Hard Wire 4-wire (2PH+N+G)
      • Receptacle Type: Hard Wire 4-Wire (2PH + N +G)
      • Receptacle Detail: 1 x Hard Wire 4-wire (2PH+N+G)
      • Application/Usage:
        • Server
        • Telecommunication

      • Efficiency: 90%

        • Power Description

      • Load Capacity (VA): 16 kVA
      • Load Capacity (Watt): 12.80 kW
      • Input Voltage: 230 V AC
      • Input Voltage Range:
        • 230 V AC - 415 V AC
        • 155 V AC - 276 V AC

      • Output Voltage:
        • 240 V AC
        • 120 V AC
        • 208 V AC

      • Input Frequency:
        • 45 Hz
        • 65 Hz

      • Output Frequency:
        • 47 Hz
        • 63 Hz
        • 50 Hz
        • 60 Hz

      • Waveform Type: Sine Wave

        • Display & Graphics

      • Display: LCD

        • Management

      • Network Management: Network Management Card

        • Interfaces/Ports

      • USB: No
      • EPO Port: Yes

        • Battery Information

      • Battery Chemistry: Lead Acid

        • Environmental Conditions

      • Maximum Operating Temperature: 104°F (40°C)
      • Storage Temperature: 5°F (-15°C) - 113°F (45°C)
      • Maximum Operating Elevation: 10000 ft
      • Maximum Storage Elevation: 15000 ft
      • Storage Relative Humidity: 0% - 95%
      • Sound Emission (A-Weighted): 62 dB(A)
      • Thermal Dissipation: 1463.89 W

        • Physical Characteristics

      • Product Color:
        • Black
        • Silver

      • Form Factor: Tower
      • Height: 36.9"
      • Width: 19"
      • Depth: 28.6"
      • Weight (Approximate): 400.84 lb

        • Miscellaneous

      • Package Contents:
        • Symmetra LX 16000VA Tower UPS
        • CD with Software
        • Installation Guide
        • User Manual
        • Web/SNMP Management Card

      • Environmental Compliance:
        • Registration, Evaluation, Authorization and Restriction of Chemicals (REACH)
        • Restriction of Hazardous Substances (RoHS)

        • Warranty

      • Limited Warranty: 2 Year
      • Additional Warranty Information:

        2 years repair or replace


        •
