APC Smart-UPS RT 20kVA Tower/Rack-mountable UPS - SURT20KRMXLI

    Product form
    • Schneider Electric SA

    APC Smart-UPS RT 20kVA Tower/Rack-mountable UPS - SURT20KRMXLI

      General Information Manufacturer: Schneider Electric SA Manufacturer Part Number: SURT20KRMXLI Manufacturer Website Address: http://www.schneider-electric.com Brand Name: APC Product Line: Smart-UPS... Read more

      Direct Ship From Manufacturer, Lead Time May Apply.

      $17,598.09

        • Need Presales Support? Contact Sales at 877-712-2230 or sales@itosolutions.net.
        • Warranty by Manufacturer
          Have a question on this product? Fill out the form below.
        Send us a message!

        SKU: UK8341
        Barcode: 0731304255710

        Size chart

        General Information

      • Manufacturer: Schneider Electric SA
      • Manufacturer Part Number: SURT20KRMXLI
      • Manufacturer Website Address: http://www.schneider-electric.com
      • Brand Name: APC
      • Product Line: Smart-UPS
      • Product Series: RT
      • Product Model: SURT20KRMXLI
      • Product Name: Smart-UPS RT 20kVA Tower/Rack-mountable UPS
      • Marketing Information:

        The APC Smart-UPS RT is an online UPS with a power rating of 20kVA and output power capacity of 16000 watts. It includes multiple output connections such as IEC 60230 C19 and IEC Jumpers. This model is includes a lead-acid battery and is rack-mountable. It features a double conversion online topology, sine wave waveform type, and built-in bypass.


      • Packaged Quantity: 1 Each
      • Product Type: Online UPS

        • Technical Information

      • Plug/Connector Type:
        • Hard Wire 3-wire
        • Hard Wire 5-wire

      • Receptacle Type:
        • Hard Wire 3-wire
        • Hard Wire 5-wire
        • IEC 60320 C19
        • IEC Jumper

      • Receptacle Detail:
        • 1 x Hard Wire 3-wire
        • 1 x Hard Wire 5-wire
        • 8 x IEC 60320 C19
        • 2 x IEC Jumper

      • Number of Battery & Surge Outlets: 21
      • Overload Protection: Yes

        • Power Description

      • Load Capacity (VA): 20 kVA
      • Input Voltage: 220 V AC
      • Output Voltage: 230 V AC
      • Waveform Type: Sine Wave

        • Management

      • Network Management: SNMP Manageable

        • Interfaces/Ports

      • Serial Port: Yes
      • Network (RJ-45): Yes

        • Battery Information

      • Battery Characteristics: Maintenance-free/Sealed/Spill Proof
      • Battery Chemistry: Lead Acid
      • Typical Battery Recharge Time: 2.50 Hour

        • Physical Characteristics

      • Product Color: Black
      • Form Factor: Rack-mountable
      • Rack Height: 12U
      • Height: 21"
      • Width: 17"
      • Depth: 30.4"
      • Weight (Approximate): 546.15 lb

        • Miscellaneous

      • Package Contents:
      • Smart-UPS RT 20kVA Tower/Rack-mountable UPS
      • CD with software
      • Rack mounting support rails
      • Smart UPS signalling RS-232 cable
      • User manual
      • Web/SNMP management card

      • Country of Origin: Philippines
      • Environmentally Friendly: Yes
      • Environmental Compliance: Restriction of Hazardous Substances (RoHS)

        • Warranty

      • Limited Warranty: 2 Year
        •
