APC Smart-UPS Ultra Tower Isolation/Step-Down Transformer, 5kVA, 8x 5-20R & 2x L6-20R & 1x L6-30R & 1x L14-30R NEMA outlets - SRTL5KTF

    Product form
    • Schneider Electric SA

    APC Smart-UPS Ultra Tower Isolation/Step-Down Transformer, 5kVA, 8x 5-20R & 2x L6-20R & 1x L6-30R & 1x L14-30R NEMA outlets - SRTL5KTF

      General Information Manufacturer: Schneider Electric SA Manufacturer Part Number: SRTL5KTF Manufacturer Website Address: http://www.schneider-electric.com Brand Name: APC Product Line: Smart-UPS... Read more

      Direct Ship From Manufacturer, Lead Time May Apply.

      $1,572.38

        • Need Presales Support? Contact Sales at 877-712-2230 or sales@itosolutions.net.
        • Warranty by Manufacturer
        • Shipped today? Order within: Sep 03, 2026 17:00:00 -0700
          Have a question on this product? Fill out the form below.
        Send us a message!

        SKU: 12CH11

        Size chart

        General Information

      • Manufacturer: Schneider Electric SA
      • Manufacturer Part Number: SRTL5KTF
      • Manufacturer Website Address: http://www.schneider-electric.com
      • Brand Name: APC
      • Product Line: Smart-UPS Ultra
      • Product Name: Smart-UPS Ultra 5kVA Tower UPS
      • Marketing Information:

        The Smart-UPS Ultra SRTL 5kW, 3U rack/tower convertible, Step-Down Transformer lets you connect multiple voltage equipment to your existing SRTL5K power protection. User Selectable: 110V/ 120V/ 208V/ 240V, depending on the UPS output voltage and the Switch position. Connections: (2) L6-20R, (8) 5-20R, (1) L6-30R, (1) L14-30R Ships as tower Configuration. Install the step-down transformer to the left/above the compatible STLR 5kW UPS. Rackmount configuration is available with SRTRK2 rail kit accessory, sold separately.


      • Packaged Quantity: 1
      • Product Type: Double Conversion Online UPS

        • Technical Information

      • Plug/Connector Type: NEMA L6-30P
      • Receptacle Type: NEMA L6-30P
      • Receptacle Detail:
        • 8 x NEMA 5-20R
        • 2 x NEMA L6-20R
        • 1 x NEMA L6-30R
        • 1 x NEMA L14-30R

      • Cord Length: 2.95 ft

        • Power Description

      • Load Capacity (VA): 5000 VA
      • Input Voltage: 208 V
      • Output Voltage: 120 V AC
      • Input Frequency: 60 Hz

        • Environmental Conditions

      • Maximum Operating Elevation: 10000 ft
      • Maximum Storage Elevation: 50000 ft
      • Storage Temperature: 5°F (-15°C) - 113°F (45°C)
      • Storage Relative Humidity: 95%
      • Maximum Operating Temperature: 104°F (40°C)

        • Physical Characteristics

      • Product Color: Black
      • Height: 17.01"
      • Width: 5.12"
      • Depth: 25.98"
      • Form Factor: Tower
      • Weight (Approximate): 125 lb

        • Miscellaneous

      • Package Contents:
        • Smart-UPS Ultra 5kVA Tower UPS
        • User Manual

      • Environmentally Friendly: Yes
      • Environmental Compliance: Restriction of Hazardous Substances (RoHS)
      • Single-use Plastic (SUP) Free Shipping Packaging: No

        • Warranty

      • Limited Warranty: 5 Year
        •
