Black Box Easy-Pull VGA Cable - EVNPS80-0100

    Product form
    • Black Box Corporation

    Black Box Easy-Pull VGA Cable - EVNPS80-0100

      General Information Manufacturer: Black Box Corporation Manufacturer Part Number: EVNPS80-0100 Manufacturer Website Address: http://www.blackbox.com Brand Name: Black Box Product Line:... Read more

      Direct Ship From Manufacturer, Lead Time May Apply.

      $603.22

      Business-to-Business Sales Only
      We sell exclusively to businesses, government agencies, educational institutions, organizations, and U.S. military bases within the United States. A valid business email address is required.

        • Need Presales Support? Contact Sales at 877-712-2230 or sales@itosolutions.net.
        • Warranty by Manufacturer
          Have a question on this product? Fill out the form below.
        Send us a message!

        SKU: 861H22
        Barcode: 0822088060048

        Size chart

        General Information

      • Manufacturer: Black Box Corporation
      • Manufacturer Part Number: EVNPS80-0100
      • Manufacturer Website Address: http://www.blackbox.com
      • Brand Name: Black Box
      • Product Line: Easy Pull
      • Product Name: Easy-Pull VGA Cable
      • Marketing Information:
        • Connect PC or RGB video sources to display devices like projectors, flat plasma screens, and more.
        • Provide 1024 x 768 video resolution up to 150 feet and 800 x 600 video resolution up to 200 feet.
        • Super flexible! They can be pulled through 3/4" conduits, and they make pull times faster.
        • Includes heat shrink tubing for permanent installation.
        • Available in six standard lengths as well as custom lengths.
        • Plenum-rated jacket.

        The cable is perfect for system integration and can connect PC or RGB video to display devices such as projectors, video walls, flat plasma screens, and monitors. It maintains excellent signal strength and provides 1024 x 768 resolution up to 150 feet (45.7 m) and 800 x 600 resolution up to 200 feet (60.9 m).

        Designed with a proprietary construction, Easy-Pull VGA Cable is flexible and simplifies system integration. It's perfect for tight spaces and shortens pull time. In fact, the cable's construction enables it to be pulled through a 3/4" conduit!

        The jacket is plenum rated. It also comes with heat shrink tubing to connect the 6-pin mini-DIN permanently.


      • Product Type: Video Cable

        • Technical Information

      • Cable Type: DIN/VGA
      • Cable Length: 100 ft
      • Connector Type on First End:
        • DIN - Male
        • HD-15 - Male

      • Connector on First End Details:
        • 1 x 6-pin DIN - Male
        • 1 x 15-pin HD-15 - Male

      • Connector Type on Second End:
        • HD-15 - Female
        • DIN - Female

      • Connector on Second End Details:
        • 1 x 15-pin HD-15 - Female
        • 1 x 6-pin DIN - Female

      • Shielding: Yes
      • Jacket Type:
        • Plenum
        • OFNP

      • Device Supported:
        • Video Device
        • Projector
        • Video Wall
        • Monitor
        • Wallplate
        • Plasma
        • PC

      • American Wire Gauge: 26 AWG
      • Supported Resolution: 1024 x 768
      • Features:
        • Flexible
        • Heat Shrink
        • Stranded

        • Physical Characteristics

      • Product Material: Tinned Copper
      • Jacket Material: Polyvinyl Chloride (PVC)

        • Miscellaneous

      • Compatibility:

        Blackbox Stainless Steel DB9 Wallplates (WP070-WP073)


      • Environmentally Friendly: Yes
      • Environmental Compliance: Waste Electrical and Electronic Equipment Directive (WEEE)
      • Country of Origin: United States
      • TAA Compliant: Yes

        • Warranty

      • Limited Warranty: Lifetime
        •
