Black Box MultiPower Miniature Transceiver/Media Converter - LGC122A-R4

    Product form
    • Black Box Corporation

    Black Box MultiPower Miniature Transceiver/Media Converter - LGC122A-R4

      General Information Manufacturer: Black Box Corporation Manufacturer Part Number: LGC122A-R4 Manufacturer Website Address: http://www.blackbox.com Brand Name: Black Box Product Line:... Read more

      24 in stock Order today, shipped 1-2 business days

      $587.40

        • Need Presales Support? Contact Sales at 877-712-2230 or sales@itosolutions.net.
        • Warranty by Manufacturer
            Have a question on this product? Fill out the form below.
          Send us a message!

          SKU: 14628442
          Barcode: 822088279235

          Size chart

          General Information

        • Manufacturer: Black Box Corporation
        • Manufacturer Part Number: LGC122A-R4
        • Manufacturer Website Address: http://www.blackbox.com
        • Brand Name: Black Box
        • Product Line: Multipower Miniature
        • Product Name: MultiPower Miniature Transceiver/Media Converter
        • Marketing Information:

          Bring fiber to the desktop more conveniently and at a lower cost than installing fiber NICs. This single-strand fiber media converter enables you to make two Ethernet connections over a duplex fiber cable, so you need to run less fiber. Black Box Miniature Media Converters make it easy to bring fiber to the desktop. Just connect a Miniature Media Converter to your PC's copper port with a CAT5 cable, then connect a fiber cable to the converter's other side. That's all there is to it! Best of all, you can tuck these tiny converters unobtrusively behind your PC. This single-mode duplex fiber converter supports distances of up to 40 kilometers (24.8 mi.). For extra versatility, you can power the Miniature Media Converter through the external AC power supply included with each converter or through the optional rackmount PowerTray (sold separately).


        • Product Type: Transceiver/Media Converter

          • Interfaces/Ports

        • Total Number of Ports: 3
        • Network (RJ-45): Yes
        • Number of Network (RJ-45) Ports: 1
        • Number of SC Ports: 2
        • SC Port Type: Duplex

          • Media & Performance

        • Media Type Supported:
          • Optical Fiber
          • Twisted Pair

        • Fiber Mode Supported: Single-mode
        • Fiber Optic Cable Wavelength: 1310 nm
        • Maximum Distance Supported: 40 km

          • Network & Communication

        • Ethernet Technology: Gigabit Ethernet
        • Network Technology:
          • 10/100/1000Base-T
          • 1000Base-X

          • Power Description

        • Power Source: AC Adapter

          • Physical Characteristics

        • Form Factor: Rack-mountable
        • Height: 0.8"
        • Width: 1.8"
        • Depth: 3.4"
        • Weight (Approximate): 1.20 lb

          • Miscellaneous

        • Package Contents:
          • MultiPower Miniature Transceiver/Media Converter
          • External 100-240-VAC, 50-60-Hz Adapter

        • Environmental Compliance: Restriction of Hazardous Substances (RoHS)
        • TAA Compliant: Yes

          • Warranty

        • Limited Warranty: 6 Year
          •
