Black Box Transceiver/Media Converter - LMC3052C-R2

    Product form
    • Black Box Corporation

    Black Box Transceiver/Media Converter - LMC3052C-R2

      General Information Manufacturer: Black Box Corporation Manufacturer Part Number: LMC3052C-R2 Manufacturer Website Address: http://www.blackbox.com Brand Name: Black Box Product Name:... Read more

      Direct Ship From Manufacturer, Lead Time May Apply.

      $692.03

        • Need Presales Support? Contact Sales at 877-712-2230 or sales@itosolutions.net.
        • Warranty by Manufacturer
          Have a question on this product? Fill out the form below.
        Send us a message!

        SKU: 681A56
        Barcode: 0822088277231

        Size chart

        General Information

      • Manufacturer: Black Box Corporation
      • Manufacturer Part Number: LMC3052C-R2
      • Manufacturer Website Address: http://www.blackbox.com
      • Brand Name: Black Box
      • Product Name: Transceiver/Media Converter
      • Marketing Information:
        • Enhanced link modes.
        • Enhanced pause capability.
        Dynamic Fiber Conversion System Tough, versatile, and manageable, the Dynamic Fiber Conversion System is a professional-grade system. It's the battleship of media conversion systems, making it perfect for the demands of your enterprise network. The Dynamic Fiber Conversion System is a chassis-and-modules solution designed to give you the maximum number of configuration options for the toughest industrial environments. The system features 19-, 5-, 2-, and 1-slot power chassis, with single or dual, AC or DC power supplies. Modules are SNMP manageable, an SNMP management module and software are available, and hot swappable (although there are special procedures for hot swapping DC power supplies). This wide range of options makes the Dynamic Fiber Conversion System ideally suited for fiber-based, carrier-class or enterprise networks. NEBS Level 3 Certification The system carries a NEBS (Network Equipment Building System) Level 3 certification, which guarantees that the equipment meets stringent durability requirements. It performs well in harsh environmental conditions and doesn't interfere with nearby electronic devices. As well, most modules have the NEBS Level 3 certification. To verify certification of individual modules, contact our FREE Tech Support.
      • Product Type: Transceiver/Media Converter

        • Interfaces/Ports

      • Total Number of Ports: 2
      • Network (RJ-45): Yes
      • Number of Network (RJ-45) Ports: 1
      • Number of SC Ports: 1
      • SC Port Type: Duplex

        • Media & Performance

      • Media Type Supported:
        • Optical Fiber
        • Twisted Pair

      • Fiber Mode Supported: Single-mode
      • Fiber Optic Cable Wavelength: 1310 nm
      • Maximum Distance Supported: 12 km

        • Network & Communication

      • Ethernet Technology: Gigabit Ethernet
      • Network Technology:
        • 1000Base-TX
        • 1000Base-LX

        • Physical Characteristics

      • Form Factor: Hot-swappable
      • Height: 2.8"
      • Width: 0.9"
      • Depth: 4.5"
      • Weight (Approximate): 8 oz

        • Miscellaneous

      • Environmentally Friendly: Yes
      • Environmental Compliance:
        • Restriction of Hazardous Substances (RoHS)
        • Waste Electrical and Electronic Equipment Directive (WEEE)

        • Warranty

      • Limited Warranty: 1 Year
        •
