Lenovo ThinkSystem Emulex LPe38102 64Gb 2-port SecureHBA PCIe Fibre Channel Adapter - 4XC7A96458

    • Direct Ship
    Product form
    • Lenovo Group Limited

    Lenovo ThinkSystem Emulex LPe38102 64Gb 2-port SecureHBA PCIe Fibre Channel Adapter - 4XC7A96458

      General Information Manufacturer: Lenovo Group Limited Manufacturer Part Number: 4XC7A96458 Manufacturer Website Address: http://www.lenovo.com/us/en/ Brand Name: Lenovo Product Model: LPe38102... Read more

      Direct Ship From Manufacturer, Lead Time May Apply.

      $5,315.67

        • Need Presales Support? Contact Sales at 877-712-2230 or sales@itosolutions.net.
        • Warranty by Manufacturer
          Have a question on this product? Fill out the form below.
        Send us a message!

        SKU: Z58269
        Barcode: 0889488759170

        Size chart

        General Information

      • Manufacturer: Lenovo Group Limited
      • Manufacturer Part Number: 4XC7A96458
      • Manufacturer Website Address: http://www.lenovo.com/us/en/
      • Brand Name: Lenovo
      • Product Model: LPe38102
      • Product Name: ThinkSystem Emulex LPe38102 64Gb 2-port SecureHBA PCIe Fibre Channel Adapter
      • Marketing Information:

        The Lenovo ThinkSystem Emulex® SecureHBA Fibre Channel Adapters by Broadcom are designed to deliver the highest level of security, performance, and manageability for mission-critical infrastructures.

        This product guide describes the Emulex FC HBAs and provides essential pre-sales information to understand the products, their key features and specifications, and compatibility. This guide is intended for technical specialists, sales specialists, sales engineers, and IT architects who want to learn more about the adapters and consider their use in IT solutions.


      • Product Type: PCIe Host Bus Adapter

        • Technical Information

      • Total Number of Fibre Channel Ports: 2
      • Host Interface: PCI Express 4.0 x8
      • Fiber Channel Port Type: N_Port
      • Features: UEFI Support

        • Media & Performance

      • Media Type Supported: Optical Fiber
      • Fiber Optic Cable Core/Cladding Specification: 50/125 µm
      • Fiber Mode Supported: Multi-mode
      • Data Transfer Rate: 64 Gbit/s

        • I/O Expansions

      • Total Number of Expansion Slots: 2
      • Expansion Slot Type: SFP+

        • Physical Characteristics

      • Form Factor: Plug-in Card
      • Height: 2.7"
      • Depth: 6.6"

        • Miscellaneous

      • Package Contents:
        • ThinkSystem Emulex LPe38102 64Gb 2-port SecureHBA PCIe Fibre Channel Adapter
        • 3U (full-height) bracket attached and 2U (low-profile) bracket
        • Publications Flyer

      • Compatibility:

        Lenovo ThinkSystem SR860 V4 Servers

        • SR630 V4 (7DG8 / 7DG9)
        • SR650 V4 (7DGC / 7DGD)
        • SR650a V4 (7DGC / 7DGD)
        • SR850 V4 (7DJT / 7DJS)
        • SR860 V4 (7DJQ / 7DJN)

      • Environmental Compliance:
        • Restriction of Hazardous Substances (RoHS)
        • China Restriction of Hazardous Substances (China RoHS)

        • Warranty

      • Limited Warranty: 1 Year
      • Additional Warranty Information:

        The adapters carry a one-year limited warranty. When installed in a supported server, the adapters assume the server's base warranty and any Lenovo Services warranty upgrade.


        •
